Mimaki JV200-130 Series
$9,995.00
The Mimaki JV200-130 Series delivers exceptional value and professional print quality in a compact, affordable design. Built for both indoor and outdoor printing, this roll-based inkjet printer combines speed, reliability, and versatility, making it ideal for banners, signage, posters, and other wide-format applications.
Powered by Mimaki’s advanced core technologies, the JV200-130 offers dual 4-color or extended 8-color ink configurations for rich, vibrant output. With bulk ink options to reduce running costs and user-friendly RIP software with ready-to-use media profiles, it ensures smooth and efficient operation. Backed by one year of Mimaki Total Care and two years of Mimaki Parts Plus+, it provides long-term confidence and support.
Key Features:
High-quality, cost-effective printing for indoor and outdoor media
Flexible ink setups: dual 4-color or 8-color options with bulk ink supply
Exceptional durability and color stability for outdoor use
User-friendly operation with included RIP software and media profiles
Backed by Mimaki Total Care (1 year) and Parts Plus+ (2 years) warranties
QUANTITY
SHIPPING & INSTALLATION
Shipping and installation are not included in the listed cost. Please call for a full quote.
SPECIFICATIONS
| Printhead |
One on-demand piezo print head (single) |
| Print resolution |
X: 600,1200 dpi | Y: 600,900,1200 dpi |
| Print speed (4 color mode) |
183 sqft/hr (17 sqm/hr) |
| Maximum Print Area |
JV200-130: 53.6 in (1361 mm) JV200-160: 63.4 in (1610 mm) |
| Maximum media width |
JV200-130: 53.9 in (1371 mm) JV200-160: 63.8 in (1620 mm) |
| Maximum Media Thickness |
up to 0.04 in (1 mm) |
| Maximum Media Weight |
55 lbs. (25 kg) |
| Ink Type |
Eco-Solvent inks: SS22 (C, M, Y, K, Lc, Lm, Lk, Or) |
| Interface |
USB 2.0 Hi-speed | Ethernet 1000 BASE-T |
| Power Supply |
AC (100-120V / 200-240V±10%) × two 50/60Hz±1Hz |
| Power Consumption |
Max. 1320W x2 | Sleep mode: 4.5W |
| Operational Environment |
Temperature 68° – 86° F (20-30° C) |
| Dimensions (W × D × H) |
JV200-130: 99 in W x 29.5 in D x 54 in H (2520 mm W ×748 mm D×1370 mm H) JV200-160: 109 in W x 29.5 in D x 54 in H (2770 mm W x 748 mm D x 1370 mm H) |
| Weight |
JV200-130: 286.6 lbs. (130 kg) JV200-160: 308.6 lbs. (140 kg) |
| Certifications |
VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA |
| Warranty Information* |
*The Mimaki Total Care warranty covers any defects in material and workmanship arising from the normal use of the product. Mimaki Total Care includes priority phone support and on-site services with labor and parts. Mimaki Parts Plus+ includes parts and phone support, with billable labor and travel expenses. For the JV/CJV200 Series, the warranty is Mimaki Total Care for year one on the full device, including labor. Years two and three are Mimaki Parts Plus+ covering all non-consumable parts. All three years cover print heads. This warranty is available for products shipped to customers in the United States and Canada. |
