STS Inks 2512 UV Flatbed Printer

Printer Details

• Master Level Intelligent Engine
• Super Stable All-Steel Frame
• Ultimate parts combination
• PLC control system
• Expanded solutions for more applications
• Industrial rigid materials output

Specifications

• Head Qty: 3-8pcs
• Resolution: Max 720 x 2400dpi
• Color: K / C / M / Y / LC / LM / W / V Optional
• Printing Size: 100 x 51 inches / 2540 x 1300mm
• Printing Thickness: 0-4 inches / 0-100mm
• Data Interface: USB
• PC: Windows 10 / Windows 11
• Printing Media: Glass, Ceramic, Metal, PVC Board, Acrylic, Wood, PU, Wallpaper etc.
• Ink Type: Eco-friendly UV-curable Ink
• Input Format: Adobe Postcript, Level 3, PDF, JPEG, TIFF, EPS, AI
• Curing: High-effect UV LED
• Printer Weight: 3,417 pounds / 1,550 KG
• Printer Size: 183 x 87 x 63 inches / 4650 x 2200 x 1600 mm
• Power: 6.5kw
• Power requirement: Single phase AC 208-240C+10%. 50/60Hz. 32A
• Environment: Independent, clean, low dust, less light, good ventilation workshop
• Temperature: 18°C – 30°C / 64°F – 86°F
• Humidity: 30% – 70% (no condensation)
• Ventilation: It is recommended to use an overhead exhaust fan 600 cfm

Printhead – Ricoh GEN5

• Draft Mode: 592sq ft/h / 55m2/h
• Production Mode: 366sq ft/h / 34m2/h
• Quality Mode: 280sq ft/h / 26m2/h

Printhead – Ricoh GEN6

• Draft Mode: 753sq ft/h / 70m2/h
• Production Mode: 484sq ft/h / 45m2/h
• Quality Mode: 377sq ft/h / 35m2/h
